Exam 350-701 topic 1 question 79 discussion

It is. A The following example displays show dot1x all command output: Device# show dot1x all Sysauthcontrol Enabled Dot1x Protocol Version 2 Dot1x Info for FastEthernet1 ----------------------------------- PAE = AUTHENTICATOR PortControl = AUTO ControlDirection = Both HostMode = MULTI_HOST ReAuthentication = Disabled QuietPeriod = 60 ServerTimeout = 30 SuppTimeout = 30 ReAuthPeriod = 3600 (Locally configured) ReAuthMax = 2 MaxReq = 2 TxPeriod = 30 RateLimitPeriod = 0 Device-871# https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/sec_usr_8021x/configuration/xe-3se/3850/sec-user-8021x-xe-3se-3850-book/config-ieee-802x-pba.html

I configured only one port on the real switch for dot1x together with the global dot1x authentication. Ran two commands to show the difference, see below and make a correct decision for the correct answer. 2960_SW3(config-if)#do sh dot1x all Sysauthcontrol Enabled Dot1x Protocol Version 3 Dot1x Info for GigabitEthernet1/0/45 ----------------------------------- PAE = AUTHENTICATOR QuietPeriod = 60 ServerTimeout = 0 SuppTimeout = 30 ReAuthMax = 2 MaxReq = 2 TxPeriod = 30 2960_SW3(config-if)#do sh dot1x int gig1/0/45 Dot1x Info for GigabitEthernet1/0/45 ----------------------------------- PAE = AUTHENTICATOR QuietPeriod = 60 ServerTimeout = 0 SuppTimeout = 30 ReAuthMax = 2 MaxReq = 2 TxPeriod = 30

A is correct

It is: A

Definitely 'A': https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/sec_usr_8021x/configuration/xe-3se/3850/sec-user-8021x-xe-3se-3850-book/config-ieee-802x-pba.html

Answer is A

xxxxxx-xxxx-xxxx-sw1#$interface gigabitEthernet 1/0/1 Dot1x Info for GigabitEthernet1/0/1 -------------------------------------------- PAE = AUTHENTICATOR QuietPeriod = 60 ServerTimeout = 0 SuppTimeout = 30 ReAuthMax = 2 MaxReq = 2 TxPeriod = 10  xxxxx-xxxx-xxxx-sw1# CCC ******************************* xxxx-xxxxx-xxxx-sw1#show dot1x all Sysauthcontrol Enabled Dot1x Protocol Version 3 Dot1x Info for GigabitEthernet1/0/1 -------------------------------------------- PAE = AUTHENTICATOR QuietPeriod = 60 ServerTimeout = 0 SuppTimeout = 30 ReAuthMax = 2 MaxReq = 2 TxPeriod = 10 Dot1x Info for GigabitEthernet1/0/2 -------------------------------------------- PAE = AUTHENTICATOR QuietPeriod = 60 ServerTimeout = 0 SuppTimeout = 30 ReAuthMax = 2 MaxReq = 2 TxPeriod = 10 !!!!!!!!! ANSWER IS A !!!!!!

A is the correct answer, because only the 'show dot1x all' command shows the 'Sysauthcontrol' status and Dot1x Protocol Version

A should show all interfaces, D only for specific interface, so both are correct, would go with D if I have to choose To display the IEEE 802.1X administrative and operational status for the switch, use the show dot1x all [details | statistics | summary] command in privileged EXEC configuration mode. To display the IEEE 802.1X administrative and operational status for a specific port, use the show dot1x interface type number command in privileged EXEC configuration mode. For detailed information about the fields in these displays, see the command reference for this release. https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/sec_usr_8021x/configuration/xe-3se/3850/sec-user-8021x-xe-3se-3850-book/config-ieee-802x-pba.html

No, is A. With D ypu donat have sysauthcontrol info

No. It's A

Should be D https://guides.co/g/cisco-trustsec-failed-authentications-and-authorizations/10982
