Refer to the exhibit, which contains a partial output of an IKE real-time debug. Based on the debug output, which phase-1 setting is enabled in the configuration of this VPN?
Correct - C according NSE7_EF_6.2 Manual p.459 and p.460
auto-discovery-sender is enabled - a shortcut-query and shortcut-reply messages are passing through
I'm unsure regarding C, could be A because on NSE7_EF_6.2 Manual p.463 it says "enable auto-discovery-receiver allows a device to receive SHORTCUT-OFFER" and I' seeing it on the image, but I'm going to try this on a lab
receiver - configured on spokes to send and receive shortcuts
forwarder - configured in multi-hub topology so that the 2nd hub can forward a shortcut offer to its connected spokes that were send by the 1st hub
sender -configured on hubs that create the shortcut offers
shortcut - does not exist
